3 Modules
The complete course consists of 3 video modules and 1 PDF manual which include self-assessment
Module 1 – Set-up & Adjustments
At the end of this module learners will be able to:
• Prepare a 20 MHz analogue type
• Identify the controls used on a typical instrument
Module 2 – Single Channel Measurements
At the end of this module learners will be able to:
• Prepare the probe for measurement
• Read amplitude / voltage measurements
• Read the time / frequency measurements
• Calculate the pulse width and duty cycle
• Calculate the rise and fall time
Module 3 – Dual Channel Operations
At the end of this module learners will be able to:
• Describe and perform dual channel operations
• Describe and perform additive and difference operations
• Describe and perform phase difference measurements
• Describe Lissajous patterns
• Describe x-y operations
• Describe and perform triggering techniques
• Describe and practice care of an oscilloscope
